Condensers, Columns and Corks

Product >>Chemistry >>Condensers, Columns and Corks

[1]

Condensers Liebig

Made from borosilicate glass. Inner tube integral with body, narrow jacket for efficient cooling. Provided with standard cone & sockets at ends.

Cat. No.	Eff.Lth.(mm.)	Socket	Cone
A	200	19/26	19/26
B	200	24/29	24/29
C	300	19/26	19/26
D	300	24/29	24/29
E	400	19/26	19/26
F	400	24/29	24/29
G	500	24/29	24/29
H	500	29/32	29/32
I	750	24/29	24/29
J	750	29/32	29/32

Condensers Allihn

Made from Borosilicate glass. An efficient condenser giving greater surface area than corresponding Liebig type due to bulb sections. Provided with standard cone & sockets at ends.

Cat. No.	Eff.Lth.(mm.)	Socket	Cone
A	200	19/26	19/26
B	200	24/29	24/29
C	300	19/26	19/26
D	300	24/29	24/29
E	400	19/26	19/26
F	400	24/29	24/29
G	500	24/29	24/29
H	500	29/32	29/32
I	750	24/29	24/29
J	750	29/32	29/32

Condensers, Graham Coil Distillate Type

Made from Borosilicate glass, Designed for high degree of coolant turbulence and permits the use of thin wall tubing without sacrificing strength. Also provides a wide vapour passage and because the outer surface is air cooled is free from external condensation of water vapour. Provided with standard cone & sockets at ends. Coil distillate type.

Cat. No.	Eff.Lth.(mm.)	Socket	Cone
A	150	14/23	14/23
B	150	19/26	19/26
C	150	24/29	24/29
D	250	19/26	19/26
E	250	24/29	24/29
F	250	29/32	29/32
G	300	24/29	24/29
H	300	29/32	29/32
I	400	29/32	29/32

Corks, Bark

Natural. All sizes are supplied in pack of 100.

Cat. No.	No	Top Dia (mm)	Bottom dia. (mm)	Length(mm)
A	000	6	4	13
B	00	8	5	13
C	0	10	7	13
D	1	11	8	16
E	2	13	9	18
F	3	14	10	19
G	4	16	11	21
H	5	17	13	22
I	6	19	14	24
J	7	21	15	25
K	8	22	16	27
L	9	23	18	28
M	10	25	19	31
N	11	30	24	31
O	12	28	22	31
P	13	30	24	31
Q	14	31	25	31
R	15	33	27	31
S	16	35	29	31
T	17	36	30	38
U	18	38	31	38
V	19	39	33	38
W	20	41	34	38

Corks, Rubber

Solid, resistance to acid, alkali and ammonia, soft red colour. Suitable for all academic, research and medical institutions.

Â Cat. No. Â	Â Size Â	Â Top Dia (mm) Â	Â Bottom dia. (mm) Â	Â Height(mm) Â
A	000	9	6	16
B	00	9.5	6.5	16
C	0	13	9	16
D	1	14	11	19
E	2	17	13	20
F	3	19	15	23
G	4	21	15	22
H	5	23	18	23
I	6	24	20	24
J	7	26	20	28
K	8	27	21	28
L	9	28	22	31
M	10	30	26	33
N	11	33	29	32
O	12	35	30	35
P	13	39	31	37
Q	14	42	32	43
R	15	42	38	41
S	16	45	37	35
T	17	50	40	41
U	18	54	48	34
V	19	54	44	45
W	20	60	51	57

Cork, Borer Set

Made of iron chrome plated. Cutting tube mounted with safety underflange in shaped handle, ensuring that operator can't be injured by a dislodged tube, with rods for clearing borers.

Cat. No.	Set	Dia (mm)
A	6	4 to 10
B	12	4 to 18
C	18	4 to 27
