Wall mounting, the Manesty still has been designed for continuous automatic and efficient production of high quality distilled water at minimum cost. The boiling chamber, condenser pipe, tube assembly and inner baffles are made of stainless steel. All electric elements are fitted with protective cut-outs. Supplied complete with brackets for wall mounting and leads with plugs. Electrical supply : 220-240V, 50-60Hz. Output (Ltr/hr) : 3 - 4. Power Consumption : 2 x 1.5kW.

The Still Glass Distillation has an elegant design. The unit is very economical with very good efficiency.

Special features :



• Sufficiently more output: The Still yields an output of 4 ltr/hr distilled water for a power consumption of 3kW Single Phase through a metal heater (chromium plated) with thermostatic cutoff system.
• The output temperature of the Still is 30°C to 40°C (approx), which is taken care by efficient cooling by double coiled Borosilicate condenser.
• The unit has two portions one boiler and the other condenser. The unit is mounted on a sturdy metal stand.
• The boiler is provided with TEFLON screw cork for easy cleaning of the boiler.

Quality of distillate

• Best for General laboratory usage.
• The conductivity of water is approx. 1.5 to 2.5 M-cm PH 5-6 PYROGEN FREE.
• The above quality of distillate is obtained by using treated water as boiler feed.
• All rubber tube connections can be made with threaded connectors.
